DFI publishes new white paper on
Crosshole Sonic Logging (CSL)
DFI announces the release of a new white paper, “Terminology
and Evaluation Criteria of Crosshole Sonic Logging (CSL) as
applied to Deep Foundations.”
The paper was produced by a CSL Task Force comprised of
members of the DFI Codes and Standards Committee, Drilled
Shaft Committee and Testing and Evaluation Committee.
The CSL Task Force was chaired by E. Anna Sellountou, PhD,
PE, Pile Dynamics.
The white paper reviews the state of practice (including
experience gained over the past 20 years), proposes improved
CSL rating criteria and makes recommendations for additional
assessment, as well as educates the industry on the proper
interpretation of CSL testing.
Non-destructive testing of drilled shaft foundations via
CSL is often performed as part of the quality assurance process
to assess the soundness of concrete. The intent of CSL testing
is to identify irregularities such as soil intrusion, necking,
soft bottom, segregation, voids and other defects that could
result in poor structural performance of the foundation.
Over time, CSL rating criteria based on first arrival time and
relative energy have often incorrectly evolved to be the sole
means of determining the acceptability of a shaft. Some of
these criteria have found their way into regulatory agency
specifications, with acceptance values often differing from
agency to agency. The 17-page paper is available at no cost at
Steel Piling USA, a new competitive
supplier of cold rolled steel piling
Based in Erie, Mich., Steel Piling USA combines the decades
of knowledge and experience of world leading manufacturers
to offer its customers a complete spread of cold formed steel
piling products. Steel Piling USA products include steel spiral
welded pipe piles, steel sheet piles and heavy wide flange
beams, which can currently be produced in lengths up to 130 feet,
as well as sealants and coatings.
Production lengths are expected to increase when Steel
Piling USA’s permanent facility is built; construction on
the 375,000 square foot facility will begin in 2020. The
manufacturing facility will be built at the Port of Monroe in
Monroe, Mich., about 10 miles from the current facility. The
location at the Port is expected to provide approximately 110
local jobs. Additionally, the proximity to Lake Erie and its
shipping routes offers Steel Piling USA superior distribution
capabilities throughout North America to fully meet its
Exclusive mill technology and capacity allow Steel Piling
USA to duplicate or improve on the shape of any hot rolled or
cold formed steel sheet piles with thicknesses up to 0.65 inches
and the highest section modulus properties in the industry.
The steel spiral welded pipes, which are double submerged
arc welded, can be produced in diameters ranging from
16 inches to 120 inches, and up to one-inch thick.
Steel Piling USA is ready for your orders today! For more
information, please visit www.steelpilingusa.com.
Innovative QA solutions driven by Pile Dynamics, Inc.
As the use of drilled foundations continues to increase,
innovative manufacturers look for ways to optimize these
foundation elements. Coming from a strong background
in deep foundations, Pile Dynamics, Inc. (PDI) can offer
the competency and expertise to develop solutions for
testing drilled shafts. The research and development team
at PDI recognizes areas of concern in drilled shaft practice
that can impact the structure’s performance. The team has
determined several quality control methods that could be
One of the desired improvements in shaft quality control
is the verticality measurement of the excavation. With no
